WD Blue 1TB SATA HDD WD10EZEX
Part# / SKU :
WD10EZEXProduct Warranty :
2 Year Limited WarrantyWD Blue 1TB SATA HDD WD10EZEX
Internal hard drive.
Technical specifications
| Model Number | WD10EZEX |
|---|---|
| Formatted capacity | 1TB |
| Recording Technology | CMR |
| Interface | SATA 6 Gb/s |
| Form factor | 3.5-inch |
| Drive Technology | Air |
| Advanced Format (AF) | Yes |
| RoHS compliant | Yes |
| Interface speed | 6 Gb/s |
| Internal Transfer Rate (max) | 150 MB/s |
| Cache (MB) | 64 |
| RPM | 7200 |
| Load/unload cycles | 300,000 |
| Non-recoverable read errors per bits read | <1 in 10^14 |
| 12VDC ± 10% (A, peak) | 2.5 |
| Power consumption, read/write (W) | 6.8 |
| Power consumption, idle (W) | 6.1 |
| Power consumption, standby/sleep (W) | 1.2 |
| Operating temperature (°C) | 0 to 60 |
| Non-operating temperature (°C) | -40 to 70 |
| Shock (Gs), Operating (2 ms, write) | 30 |
| Shock (Gs), Operating (2 ms, read) | 65 |
| Shock (Gs), Non-operating (2 ms) | 350 |
| Acoustics, idle (dBA) | 29 |
| Acoustics, seek average (dBA) | 30 |
| Height (max) (in / mm) | 1.028 / 26.1 |
| Length (max) (in / mm) | 5.787 / 147 |
| Width (± .01 in.) (in / mm) | 4 / 101.6 |
| Weight (± 3% ) (lb / kg) | 0.99 / 0.45 |
| Drive capacity | 1TB |
| Drive form factor | 3.5-inch |
| Drive interface | SATA 6 Gb/s |
| Drive recording method | CMR |
| Drive speed | 7200 RPM |
| HDD Capacity | 1TB |
| HDD Form Factor | 3.5-inch |
| HDD Interface | SATA 6 Gb/s |
| HDD Speed | 7200 RPM |
| HDD Recording Method | CMR |
