TP-Link ES208G 8-Port Gigabit Switch
- 8 Gigabit Auto-Negotiation RJ45 ports, Supports Auto MDI / MDIX
- Green Ethernet technology saves power consumption
- IEEE 802.3x flow control provides reliable data transfer
- Plastic case, desktop or wall-mounting design
- Plug and play, no configuration required
Part# / SKU :
ES208GProduct Warranty :
3 Year Limited WarrantyBarcode :
1210002600668| Manufacturer model | ES208G |
|---|---|
| Product type | Ethernet switch |
| Interface | • 8× 10/100/1000 Mbps RJ45 Ports• Auto-Negotiation/Auto MDI/MDIX |
| Fan Quantity | Fanless |
| Installation | • Desktop• Wall Mounting |
| Physical Security Lock | √ |
| Power Supply | AC/DC Adapter (Input: 100-240V AC; Output: 5V DC/0.6A) |
| Net Weight | 0.45 kg (0.99 lbs) |
| Dimensions ( W x D x H ) | 6.2 × 4.0 × 1.0 in (158 × 101 × 25 mm) |
| Surge Protection | ±6 kV |
| Packet Buffer Memory | 4 Mbit |
| Jumbo frame | 15 KB |
| Switching capacity | 16 Gbps |
| Packet forwarding rate | 11.9 Mpps |
| MAC Address Table | 8K |
| Quality of Service | • 802.1p DSCP QoS• 8 Priority Queues• Priority Schedule Mode- WRR (Weighted Round Robin) • Queue Weight Config • Bandwidth Control - Port-Based Rating Limit • Storm Control - Multiple Control Modes (kbps/pps) - Broadcast/Multicast/Unknown-Unicast Control |
| L2 Features | • Link Aggregation (Static Link Aggregation; Up to 2 aggregation groups and up to 4 ports per group) • Loopback Detection • Flow Control- 802.3x Flow Control • Mirroring (Port Mirroring; One-to-One; Many-to-One; Ingress/Egress/Both) • Port Statistics (Port Mirror Status; Traffic Statistics) • 802.1ab LLDP |
| L2 Multicast | • IGMP Snooping - IGMP v1/v2/v3 Snooping - Fast Leave |
| VLAN | • MTU VLAN • Port-Based VLAN • 802.1Q Tag VLAN - Max 32 VLAN Groups - 4K VID |
| Transmission method | Store-And-Forward |
| Omada App | Yes. Requires the use of Omada Controller. |
| Centralized Management | • Omada Cloud-Based Controller • Omada Hardware Controller • Omada Software Controller |
| Cloud Access | Yes. Requires the use of Omada Controller. |
| Zero-Touch Provisioning | Yes. Requires the use of Omada Cloud-Based Controller |
| Management Features | • Web-based GUI • DHCP Client • Cable Diagnostics • Automatic Device Discovery † • Batch Configuration † • Batch Firmware Upgrading † • Unified Configuration † |
| Certification | FCC, CE |
| Environment | • Operating Temperature: -5℃~45℃ (23℉~113℉) • Storage Temperature: -40℃~70℃ (-40℉~158℉) • Operating Humidity: 10%~90% non-condensing • Storage Humidity: 5%~90% non-condensing |
| Ethernet ports | 8 |
| Ethernet speed | 1Gbps |
