NZXT Case H5 Elite White 2x140mm & 1x120mm CC-H51EW-01
Part# / SKU :
CC-H51EW-01H5 Elite (2022)
Supported motherboard formats: ATX, Micro-ATX, Mini-ITX.
Technical specifications
| Height (with Feet) | 464 mm (18.27 in) |
|---|---|
| Width | 227 mm (8.94 in) |
| Depth | 446 mm (17.56 in) |
| Weight | 8.1 kg |
| Enclosure Type | Compact ATX Mid-Tower |
| Motherboard Compatibility | ATX Micro-ATX Mini-ITX |
| Supports Back Connect Motherboards (BTF, Project Zero, etc.) | No |
| Included Controller | NZXT RGB Controller |
| CPU Cooler Height | 165 mm |
| GPU Length | Up to 365 mm (w/o front fans or radiator) |
| Cable Management Clearance | Up to 23 mm |
| Front Fan & Radiator Clearance | Up to 45 mm |
| Front I/O Ports - USB Type-A | 1 |
| Front I/O Ports - USB Type-C | 1 |
| Front I/O Ports - 3.5 mm Headset Jack | 1 |
| Expansion Slots - Standard | 7 |
| Expansion Slots - Vertical | 0 |
| Expansion Slots - Vertical GPU Mounting Kit Compatible | Yes |
| Drive Bays - 2.5" | 1 + 1 |
| Drive Bays - 3.5" | 1 |
| Fan Support - Front | Up to 2 x 120 mm Up to 2 x 140 mm |
| Fan Support - Top | Up to 2 x 120 mm |
| Fan Support - Rear | 1 x 120 mm |
| Fan Support - Bottom | 1 x 120 mm |
| Radiator Support - Front | Up to 240 mm (120 mm base) Up to 280 mm (140 mm base) |
| Radiator Support - Top | Up to 240 mm (120 mm base) |
| Radiator Support - Rear | Up to 120 mm |
| UPC | H5 Elite 810074842440 (Black) 810074842457 (White) |
| EAN | H5 Elite 5056547202365 (Black) 5056547202372 (White) |
| Manufacturer model | H5 Elite (2022) |
| Manufacturer part number | CC-H51EB-01 |
| Materials | SGCC steel and tempered glass |
| Included fans - Front | 2 x F140 RGB Fan |
| Included fans - Top | None |
| Included fans - Rear | None |
| Included fans - Bottom | 1 x F120Q Airflow Fan (Case Version) |
| Case Form Factor | Mid-Tower |
| Maximum GPU Length | 365 mm |
