Cooler Master Elite Gold 850w MPX-8505-AFAG-NBIN
Product Warranty :
Five Year WarrantyBarcode :
4719512163498Cooler Master Elite Gold 850w MPX-8505-AFAG-NBIN
Rated output: 850W. Efficiency certification: 80 Plus Gold. Fully modular outputs allow the required cables to be connected. Cooling: 120mm. Protection: UVP / OVP / OPP / OTP / SCP.
Technical specifications
| Model | MPX-8505-AFAG |
|---|---|
| ATX Version | ATX 12V Ver. 3.1 |
| PFC | Active PFC |
| Input Voltage | 100-240V |
| Input Current | 6 ~ 12A |
| Input Frequency | 50-60Hz |
| Dimensions (L x W x H) | 140 x 150 x 86 mm |
| Fan Size | 120mm |
| Fan Bearing | Rifle bearing |
| Efficiency | ≥90% @ Typical Load |
| 80 PLUS Rating | 80 PLUS Gold |
| ErP 2014 Lot 3 | Yes |
| Operating Temperature | 0-40°C |
| Power Good Signal | 100 - 150 ms |
| Hold Up Time | ≥ 11ms @ 100% Load |
| MTBF | >100,000 hours @ 25℃ ambient |
| Protections | UVP / OVP / OPP / OTP / SCP |
| Regulatory | cTUV us, CB, CE, FCC, BSMI, CCC, RCM, UKCA, BIS, RoHS2.0 |
| ATX 24 Pin Connectors | x1 = 1 (550mm) |
| EPS 4+4 Pin Connectors | x1 = 1 (600mm) |
| EPS 8 Pin Connector | x1 = 1 (600mm) |
| SATA & Peripheral 4 Pin Connectors | X4(s) + x2(p) = 2 [400(s)+120(s)+120(p) mm] |
| PCI-e 6+2 Pin Connectors | x3 = 1 (500+120mm), 1 (500mm) |
| 12+4 Pin Connectors | x1 = 1 (650mm) |
| Form Factor | ATX |
| Watts | 850W |
| Modular | Fully Modular |
| 80 Plus Efficiency | Gold |
| Power | 850W |
| Efficiency rating | 80 Plus Gold |
