CM PSU MWE BRONZE V2 450W MPE-4501-ACABW-BIN
Part# / SKU :
MPE-4501-ACABW-BINProduct Warranty :
5 Year Warranty From ManufacturerBarcode :
4719512103821CM PSU MWE BRONZE V2 450W MPE-4501-ACABW-BIN
Rated output: 450W. Efficiency certification: 80 Plus Bronze. Fixed output cables. Cooling: 120mm. Protection: OVP; OPP; SCP; UVP; OTP.
Technical specifications
| PFC | Active PFC |
|---|---|
| ErP 2014 Lot 3 | Yes |
| Input Frequency | 50-60Hz |
| ATX 24 Pin Connectors | 1 |
| EPS 4+4 Pin Connectors | x1 = 1x (700mm)1 |
| Fan Size | 120mm |
| Power Good Signal | 100 - 500 ms |
| MTBF | >100,000 hours @ 25℃ ambient |
| Modular | Non Modular |
| Fan Bearing | HDB |
| 80 Plus Efficiency | Bronze |
| PCI-e 6+2 Pin Connectors | 2 |
| SATA Connectors | 6 |
| Fan Speed | 1500 RPM |
| Efficiency | 88% Typically |
| 80 PLUS Rating | 80 PLUS Bronze EU 230V |
| ATX Version | ATX 12V V2.52 |
| Protections | OVP; OPP; SCP; UVP; OTP |
| Peripheral 4 Pin Connectors | 3 |
| Hold Up Time | >14ms at 100% Full Load@230Vac |
| Noise Level @ 20% | 11.18 dBA |
| Dimensions (L x W x H) | 140 x 150 x 86 mm |
| Noise Level @ 100% | 29.5 dBA |
| Noise Level @ 50% | 17.1 dBA |
| Input Voltage | 200-240Vac |
| Regulatory | CCC; CE; TUV-RH; RCM; EAC; cTUVus; FCC; BSMI; KC; CB |
| Model | MPE-4501-ACABW-B |
| Rated output power | 450W |
| Maximum output current | +5V:15A; +3.3V:15A; +12V:37A; -12V:0.3A; +5VSB:3A |
| Maximum combined wattage | +5V/+3.3V:100W; +12V:444W; -12V:3.6W; +5VSB:15W |
| Power | 450W |
| Efficiency rating | 80 Plus Bronze |
