AOC 22" 22B30HM2 Monitor
Part# / SKU :
22B30HM2Product Warranty :
3 Year Limited WarrantyBarcode :
8906060330588AOC 22" 22B30HM2 Monitor
A 21.45" VA display with FHD 1920 x 1080 resolution. Refresh rate: 100 Hz. Refer to the specifications for connection and operating-mode limits. Connections: 1 xVGA;1 xHDMI1.4. Stand adjustment: Tilt -5 to23 degrees. Audio: No.
Technical specifications
| Model | 22B30HM2 |
|---|---|
| Panel | 21.45 inches;VA |
| Pixel Pitch | 0.2493 x0.241 mm |
| Effective Viewing Area | 478.66 x260.28 mm |
| Brightness | 250 cd/m2 |
| Contrast Ratio | 3000:1 typical;20 Million:1 DCR |
| Response Time | 4 ms GtG /1 ms MPRT |
| Viewing Angle | 178 degrees horizontal / vertical (CR >10) |
| Color Gamut | NTSC86% (CIE1976);sRGB102% (CIE1931) |
| Optimum Resolution | 1920 x1080 at100 Hz over HDMI;75 Hz over VGA |
| Display Colors | 16.7 Million |
| Signal Input | 1 xVGA;1 xHDMI1.4 |
| HDCP | HDMI1.4 |
| USB Hub | No |
| Power Supply | External19V DC;1.31A |
| Typical Power Consumption | 17 W |
| Speakers | No |
| Audio Output | No |
| VESA Wall Mount | 100 x100 mm |
| Stand Adjustment | Tilt -5 to23 degrees |
| Dimensions without Stand (H x W x D) | 284.8 x493.8 x35.8 mm |
| Dimensions with Stand (H x W x D) | 379.1 x493.8 x169.9 mm |
| Package Dimensions (H x W x D) | 350 x565 x93 mm |
| Weight without Stand | 1.79 kg |
| Weight with Stand | 2.02 kg |
| Package Weight | 3.49 kg |
| Screen Size | 21.45" |
| Resolution | FHD 1920 x 1080 |
| Refresh Rate | 100 Hz |
| Panel Type | VA |
