Ant Esports Case SX7 Black
Part# / SKU :
SX7 BlackProduct Warranty :
1 Year Warranty From ManufacturerAnt Esports Case SX7 Black
Supported motherboard formats: ATX, Micro-ATX, Mini-ITX. Maximum stated graphics-card clearance is 360 mm.
Technical specifications
| Dimension (L x W x H) | Chassis Size: 410 x 210 x 450 mm Packing Size: 497 x 262 x 468 mm |
|---|---|
| Motherboard Type | ATX, Micro-ATX, Mini-ITX |
| Drive Bays | 3.5Inch x2 2.5Inch x2 5.25Inch x0 |
| Fan Support | Front: 120mm x3 / 140mm x3 Top: 120m x2 /140mm x2 Bottom: 120m x2 Rear: 120mm x1 Side: None |
| Liquid Cooling Support | Front: 120/240/280/360 mm Rear: 120 mm Top: 120/240/280 mm |
| Pre-Installed Fans | Front: x3 |
| Compatibility (Maximum) | VGA Card Length: 360mm CPU Cooler Height: 165mm |
| I/O Panel | USB 2.0 x2, USB 3.0 x1, Audio In / Mic In (TRIRS Port), LED Button |
| Expansion Slots | 7 |
| Case Type | Mid-Tower |
| Maximum GPU Length | 360 mm |
| Maximum CPU Cooler Height | 165 mm |
| Case Form Factor | Mid-Tower |
